Measuring
Range: Pulse-Echo Mode: (Pit&Flaw Detection) measures from 0.025 in. to 100 ft. (0.63 mm to 30.48 M).
Echo-Echo Mode: Thru Paint & Coatings) measures from 0.100 to 6.0 in. (2.54 to 152.4 mm). Range will vary +/- depending on the thickness of coating.
Resolution: +/- .001 inches (0.01 mm)
Velocity Range: .0122 to .7300 in./ms (309.88 to 18542 M/sec
Single and Two point calibration option, or selection of basic material types.
Units: English & Metric
Transducer
Transducer Types: Dual Element (1 to 10 MHz).
Locking quick disconnect “00” LEMO connectors.
Standard 4 foot cable.
Custom transducers and cable lengths available for special applications.
